LOAD CELL

Description

• Brand: Zemic
• Model: H8C
• Type: Single Ended Shear Beam
• Capacity: 300Kg / 500Kg / 1000 Kg
• Material: Stainless Steel
• Ingress Protection: IP67
• Application :Platform Scale
• Features: Hermetically sealed
• Load Cell Certifications :OIML, NTEP
• Output Sensitivity(FS): 3.0 +/- 0.003 mV/V
• Combined Error: <= +/- 0.023
• Creep Error (30 minutes) :<= +/- 0.016
• Accuracy Class: OIML R60 C3
• Temperature Effect on Zero: <= +/- 0.015
• Temperature Effect on Output: <= +/- 0.011
• Zero balance: +/- 1% FS
• Maximum Safe Overload :150% FS
• Ultimate Safe Overload :300% FS
• Recommended Excitation Voltage :5 to 12V DC
• Maximum Excitation Voltage : 18V DC
• Input Resistance: 350 +/- 3.5 Ohm
• Output Resistance:350 +/- 3.5 Ohm
• Insulation resistance at Voltage :> = 5000 M
• Compensated Temperature Range: -10 to +40 Deg C
• Operating Temperatue C Range: -35 to +65 Deg
• Load Cell Intervals (nLC)/Divisions:3000
• Cable Length: 4 Meter

We deal in good quality Single Ended Load Cell with the most
premium standards and performance available

Features:

• Stainless Steel, Welded Seal Construction
• Hostile or Clean Environment
• Food & Beverage Processing
• Chemicals & Plastics Processing
• Tank, Bin & Hopper Weighing
• Batching, Blending & Mixing Systems
